Name: High Flexibility Electrical Epoxy Resin with Low Curing Shrinkage and Glass Transition Temperature 100-120°C for Electrical Insulation
Brand: Shanghai Wenyou Industry Co., Ltd.
SKU: 9218F
Price: 2.6 USD
Availability: InStock

Casa > prodotti > Resina epossidica elettrica >

High Flexibility Electrical Epoxy Resin with Low Curing Shrinkage and Glass Transition Temperature 100-120°C for Electrical Insulation

Luogo di origine:

Cina

Marca:

Wenyou

Certificazione:

UL/SGS/REACH/RoHS

Numero di modello:

9218F

Documento:

Wenyou catalogue-2024.pdf

Contattici

Richieda una citazione

High Flexibility Electrical Epoxy Resin with Low Curing Shrinkage and Glass Transition Temperature 100-120°C for Electrical Insulation

Dettagli del prodotto

Fare domanda a:

trasformatore ad alta tensione

Flessibilità:

Alto

Riduzione di resistenza:

00,8-1,0%

Applicazione:

Isolamento elettrico

Utilizzo:

isolamento eletric

Temperatura di transizione in vetro:

100-120°C

Termini di trasporto & di pagamento

Quantità di ordine minimo

240 kg

Prezzo

$2.6

Imballaggi particolari

20 kg/220 kg

Tempi di consegna

entro 10 giorni

Termini di pagamento

L/c, t/t

Capacità di alimentazione

200ton/mese

Prodotti correlati

High Flexibility Electrical Epoxy Resin with Low Curing Shrinkage and Glass Transition Temperature 100-120°C for Electrical Insulation

Ottenga il migliore prezzo

9218 Resina epossidica elettrica ad alta resistenza all'urto 10-18kJ/m² Basso fattore di perdita

Ottenga il migliore prezzo

video

Flame Retardant Epoxy Resin Potting Compound with 10-35kV Electrical Insulation and Modified Saturated Epoxy Resin

Ottenga il migliore prezzo

Electrical Insulation Epoxy Resin and Liquid Mold Electrical Insulation Epoxy Resin for Medium&high Voltage Transformer

Ottenga il migliore prezzo

Contattici

008618018933365

Elliot.yang@sh-wysy.com

86-21-64308192

Contatto ora

Descrizione di prodotto

WENYOU 9218 Electrical Epoxy Resin

Premium-grade adhesive solution engineered for critical electrical insulation and bonding applications. This light yellow to colorless liquid combines exceptional mechanical strength with superior dielectric properties, making it ideal for sealing and protecting sensitive electronic components in demanding environments.

Key Features & Advantages

High Impact Resistance: Withstands 10-18kJ/m² (ISO179) for durable component protection
Low Electrical Loss: Minimal dissipation factor of 0.02 ensures energy efficiency
Thermal Stability: Glass transition temperature (Tg) of 100-120°C (ISO11357-2)
Flame Retardant: HB flammability rating (4mm thickness) enhances safety
Precision Curing: Controlled shrinkage (0.6-0.8%) maintains dimensional accuracy

Technical Specifications

Property	Test Standard	Value Range
Compressive Strength	ISO604	150-200 N/mm²
Flexural Strength	ISO178	110-140 N/mm²
Tensile Strength	ISO527	60-85 N/mm²
Epoxy Value	ISO3001	4.4-4.9
Density at 25°C	ISO1675	1.16-1.2 g/cm³
Dielectric Strength	-	20-30 kV/mm
Cure Temperature	-	130-140°C
Viscosity at 25°C	ISO12058	5.5-8.5 MPa*s

Applications

Transformer and bushing insulation
Circuit board encapsulation
High-voltage cable jointing
Switchgear component bonding
Aerospace electrical systems

Frequently Asked Questions

Q: What certifications does this resin hold?

A: REACH/RoHS/UL/SGS certifications with custom compliance options.

Q: What's the minimum order quantity?

A: 240 KG with standard 20KG/220kg packaging.

Q: How soon can orders ship?

A: Guaranteed dispatch within 10 business days.

Q: Is customization available?

A: Yes, technical parameters can be adjusted for specialized applications.

Q: What payment methods are accepted?

A: L/C and T/T transactions.
